Cold Room PUF Panels & Accessories - Complete System Solutions

Complete Cold Room Solutions

Ice Make delivers comprehensive cold room solutions that integrate seamlessly to create optimal temperature-controlled environments. Our complete package includes high-performance PUF panels, specialized doors with accessories, and efficient refrigeration units, all engineered to work together for maximum performance and energy efficiency.

Advanced Manufacturing Infrastructure

Our state-of-the-art manufacturing facility is equipped with cutting-edge technology to produce highly durable thermal insulated PUF panels. With precision engineering and quality control systems, we ensure each panel meets the highest standards for thermal performance, structural integrity, and longevity.

Superior Thermal Performance

Our most resilient PUF panels deliver substantial energy savings through superior thermal insulation properties. The advanced foam technology and precision manufacturing process create panels that maintain consistent temperatures while minimizing energy consumption, resulting in significant operational cost savings over the system's lifetime.

Innovative Assembly System

Advanced Cam-Lock Technology:

• Easy assembly and disassembly capability
• Long-lasting mechanical connections
• Optimal configurations for all applications
• Versatile installation for walls, corners, ceilings, floors, and door frames

Wall-to-Ceiling Integration:

• Specialized cam-lock joints for seamless connections
• Eliminates thermal bridging
• Facilitates ideal modular cold room design
• Enhanced structural stability

Technical Specifications

PUF Panel Thickness Options

Our comprehensive range accommodates diverse thermal requirements:

• 60mm: Ideal for moderate temperature applications
• 80mm: Standard commercial cold storage
• 100mm: Enhanced insulation for demanding applications
• 125mm: Superior performance for extreme temperature requirements
• 150mm: Maximum insulation for ultra-low temperature storage

Surface Material Options

Galvanized Iron (GI) Pre-Painted Sheet:

• Durable powder-coated finish
• Excellent corrosion resistance
• Wide color selection available
• Cost-effective solution

Stainless Steel Sheet:

• Grade 304: Standard food-grade applications
• Grade 316: Enhanced corrosion resistance for harsh environments
• Finish Options: 2B (standard) and Matte finish
• Superior hygiene and cleanability
• Long-term durability

GI Plain Sheet:

• Economical option for basic applications
• Suitable for dry storage environments
• Good structural properties

Plain Galvanized Iron:

• Enhanced corrosion protection
• Suitable for high-humidity environments
• Reliable long-term performance

Flexible Configuration: Different metals can be specified for interior and exterior surfaces based on specific application requirements, allowing optimization for both performance and cost.

Floor System Options

Option A - Basic Insulated Floor:

• PUF slab construction
• Tar felt coating on both sides
• Suitable for Kota stone or concrete base floors
• Cost-effective solution for standard applications

Option B - Metal Surface Floor:

• Metal surface panels on both sides
• Integrated cam-lock system
• Prevents temperature loss through floor
• Enhanced thermal performance
• Compatible with Kota stone or concrete base

Option C - Heavy-Duty Floor:

• Aluminum checkered plate surface
• Marine plywood backing
• Excellent slip resistance
• Suitable for high-traffic applications
• Enhanced durability

Option D - Chemical-Resistant Floor:

• FRP (Fiberglass Reinforced Plastic) cladding
• Superior chemical resistance
• Easy cleaning and maintenance
• Ideal for pharmaceutical and chemical applications

Room Dimensions

Minimum Specifications:

• Minimum length and width: 1.78m
• Expandable in 0.146m increments
• Custom dimensions available for specific requirements

Standard Heights by Panel Thickness:

• 60mm panels: 2.47m standard height
• 80mm panels: 2.51m standard height
• 100mm panels: 2.55m standard height
• 125mm panels: 2.60m standard height
• 150mm panels: 2.65m standard height

Custom Height Capability: Single panel heights up to 12m and beyond, engineered to meet specific application requirements.

Door Solutions

Flush Type Doors

Advanced Construction:

• FRP profile frame for superior durability
• Imported hardware for reliable operation
• Push-type gasket system for optimal sealing
• Replaceable electrical wire heater for easy maintenance

Available Opening Sizes:

• 24″ × 72″ (610mm × 1829mm)
• 30″ × 72″ (762mm × 1829mm)
• 34″ × 78″ (864mm × 1981mm)
• 46″ × 84″ (1168mm × 2134mm)

Key Features:

• Effortless operation in extreme temperatures
• Enhanced durability through quality materials
• Easy maintenance and service access

Overlap Type Doors

Robust Construction:

• Teak wood frame with metal covering
• Heavy-duty hardware for enhanced strength
• Traditional design with modern performance
• Suitable for high-usage applications

Available Sizes:

• 45″ × 84″ (1143mm × 2134mm)
• 49″ × 84″ (1245mm × 2134mm)
• 54″ × 84″ (1372mm × 2134mm)
• 60″ × 90″ (1524mm × 2286mm)

Sliding Door Systems

Complete Installation Package:

• Pre-assembled unit for easy installation
• All fittings included
• Sliding rail system
• Bottom guide rollers for smooth operation

Specifications:

• Width Options: 1000mm, 1200mm, 1500mm, 1800mm
• Height Range: 2100mm to 3000mm
• Standard Thickness: 80mm
• Enhanced Thickness Options: 100mm available

Performance Features:

• User-friendly operation
• High efficiency sealing
• Exceptional performance in extreme temperatures
• Safety-focused design
• Long service life with smooth daily operation

Essential Accessories

Vision Systems

View Port (12″ × 12″):

• Triple-layer construction
• Argon-filled toughened glass
• Temperature visibility capability up to 2°C
• Professional-grade observation window

Hatch Window:

• Multiple size options available
• Robust frame construction
• Designed for material handling efficiency
• Ideal for high-turnover ice cream and dairy operations

Environmental Control

Strip Curtain:

• Semi-transparent PVC construction
• Optimized for negative temperature applications
• Effectively prevents heat infiltration
• Reduces power consumption
• Easy installation and maintenance

Pressure Ventilator:

• Tru-action pressure ventilator technology
• Available with or without integrated heater
• Maintains balanced pressure and vacuum
• Prevents structural stress from pressure differentials

Operational Accessories

Ramps:

• Designed for seamless trolley movement
• Protects door frames from damage
• Various configurations available
• Heavy-duty construction

Wall Guards:

• Protects panel surfaces from impact damage
• Strategic placement for high-traffic areas
• Durable construction materials
• Easy installation and replacement

Safety & Monitoring Systems

Inside Safety Alarm:

• Emergency notification system
• Personnel safety protection
• Audible and visual alarm options
• Battery backup capability

High-Low Temperature Alarm:

• Continuous temperature monitoring
• Programmable temperature thresholds
• Early warning system for temperature deviations
• Prevents product loss through early detection

Swing Door Accessories:

• Enhanced hardware packages
• Safety features for personnel protection
• Improved sealing systems
• Extended operational life components

Quality Assurance & Performance

Manufacturing Excellence

• Precision-engineered components
• Quality control at every production stage
• Comprehensive testing protocols
• Certified performance standards

Installation Support

• Professional installation teams
• Complete technical documentation
• On-site commissioning services
• Performance verification testing

Long-Term Value

• Superior energy efficiency reduces operational costs
• Durable construction ensures extended service life
• Modular design allows for future expansion
• Comprehensive warranty coverage

Ice Make Cold Room PUF Panels & Accessories represent the pinnacle of temperature-controlled storage technology, combining superior materials, innovative design, and precision manufacturing to deliver reliable, efficient, and cost-effective solutions for diverse cold storage applications.
